CNC Multi Power Super Vise
|
MODEL |
HPAC-100S |
HPAC-130S |
HPAC-160S |
|
A |
127 |
147 |
160 |
|
B |
85±0.01 |
95±0.01 |
105±0.01 |
|
C |
0-170 |
0-190 |
0-250 |
|
C1 |
115-280 |
155-340 |
190-430 |
|
D |
75±0.02 |
75±0.02 |
80±0.02 |
|
E |
18 |
18 |
18 |
|
F |
414 |
462 |
532 |
|
G |
4460 |
510 |
580 |
|
H |
100 |
130 |
160 |
|
I |
19 |
19 |
19 |
|
J |
15 |
15 |
15 |
|
K |
175 |
178 |
183 |
|
L |
44 |
44 |
58 |
|
M |
153 |
153 |
196 |
|
Max. clamping force |
5000kgs |
6000kgs |
8000kgs |
|
weight |
32 |
46.5 |
64 |
Material: FCD 60 Ductile Iron; Hardness: HRC 50°.
*Shortest length with big jaw opening.
*Extremely high accuracy and repeatability.
*Special Multi-Power design enhances clamping force of 0~8000kgs.
|
MODEL |
HPAQ-160 |
HPAQ-200 |
HPAQ-250 |
HPAQ-160L-400 |
HPAQ-160L-500 |
HPAQ-160L-650 |
HPAQ-160L-480 |
HPAQ-160L-730 |
HPAQ-160L-1140 |
|
A |
168 |
187 |
187 |
168 |
168 |
168 |
187 |
187 |
187 |
|
B |
115± 0.01 |
120± 0.01 |
115± 0.01 |
115± 0.01 |
115± 0.01 |
115± 0.01 |
120± 0.01 |
120± 0.01 |
120± 0.01 |
|
C |
0-300 |
0-350 |
0-350 |
0-400 |
0-500 |
0-650 |
0-480 |
0-730 |
0-1140 |
|
C1 |
195-490 |
220-570 |
220-280 |
206-600 |
206-700 |
206-860 |
236-710 |
236-960 |
236-1370 |
|
D |
57±0.02 |
66±0.02 |
66±0.02 |
57±0.02 |
57±0.02 |
57±0.02 |
66±0.02 |
66±0.02 |
66±0.02 |
|
E |
18 |
||||||||
|
F |
560 |
637 |
656 |
665 |
765 |
925 |
795 |
1045 |
1435 |
|
G |
677 |
754 |
763 |
792 |
892 |
1042 |
912 |
1162 |
1560 |
|
H |
160 |
200 |
250 |
160 |
160 |
160 |
200 |
200 |
200 |
|
I |
19 |
||||||||
|
J |
15 |
18 |
18 |
15 |
15 |
15 |
18 |
18 |
18 |
|
J1 |
21 |
25 |
25 |
21 |
21 |
21 |
25 |
25 |
25 |
|
K |
53 |
66 |
66 |
53 |
53 |
53 |
66 |
66 |
66 |
|
K1 |
63 |
75 |
75 |
63 |
63 |
63 |
75 |
75 |
75 |
|
L |
117 |
||||||||
|
M |
145 |
168 |
168 |
145 |
145 |
145 |
168 |
168 |
168 |
|
Max. clamping force |
8000kgs |
||||||||
|
weight |
73 |
120 |
156 |
83 |
92 |
107 |
144 |
175 |
217 |
Material: FCD 60 Ductile Iron; Hardness: HRC 50°.
*Shortest length with big jaw opening.
*Extremely high accuracy and repeatability.
*Special Multi-Power design enhances clamping force of 8000kgs.
